A gentle introduction to genetic algorithms with Go

The quote has 18 characters (including space). The probability of the monkey typing ’t’ (let’s be generous and say it’s ok to be all small caps) is 1 out of 26. So the probability of typing the exact sequence “To be or not to be” is 1 out of 26 to the power of 18 or 1 out of about 29,479,510,200,013,920,000,000,000. If let’s say the monkey type a letter every second, there is just 1 chance out of 934,789,136,225,707,600 years that it will type out that quote. That’s 1 time in 934 trillion years.

Obviously the brute force way of doing this is not going to get us anywhere. What if we try to ‘evolve’ the quote? Let’s look at how we can use genetic algorithms to do this. Here are the steps for a genetic algorithm used to solve the problem:

Define an organism consisting of one or more DNA

An organism in our Shakespeare-spouting algorithm consists of a single DNA, which is a byte array and a number representing the fitness of the Organism.

type Organism struct {
DNA []byte
Fitness float64
}

Start with an initial population of organisms

We need to create organisms for our initial population, so here’s a function to do that.

func createOrganism(target []byte) (organism Organism) {
ba := make([]byte, len(target))
for i := 0; i < len(target); i++ {
ba[i] = byte(rand.Intn(95) + 32)
}
organism = Organism{
DNA: ba,
Fitness: 0,
}
organism.calcFitness(target)
return
}

The target is what we want to achieve, in this case, it is the byte array representation of the string ‘to be or not to be’. In this function, we randomly create a byte array of the same length as the target and set that as the value of the gene in the newly created Organism.

Now that we can create Organisms, we need to create a population of them.

func createPopulation(target []byte) (population []Organism) {
population = make([]Organism, PopSize)
for i := 0; i < PopSize; i++ {
population[i] = createOrganism(target)
}
return
}

The population is an array of Organisms while PopSize is a global variable defining the size of the population.

Find the fitness of the organisms

We need to calculate the fitness of organisms in our population. This was called earlier in when we created the Organism but will also be called later when we crossover Organisms.

func (d *Organism) calcFitness(target []byte) {
score := 0
for i := 0; i < len(d.DNA); i++ {
if d.DNA[i] == target[i] {
score++
}
}
d.Fitness = float64(score) / float64(len(d.DNA))
return
}

This fitness function is relatively simple. We simply count the number of times the bytes in the gene matches the target. The score is divided by the total number of bytes in the target in order to get the fitness to be a percentage i.e. a number between 0.0 and 1.0. This means if the fitness is 1.0, we would have evolved the Organism’s gene to match the quote ‘to be or not to be’.

Select the organisms with the best fitness and give them higher chances to reproduce

Now that we have a population, and we can figure out which organisms have the best fitness, we want to pick the best fit organisms and let them reproduce to create the next generation of the population. There are many different ways of doing this but in this case, we’re using a ‘breeding pool’ mechanism.

func createPool(population []Organism, target []byte, maxFitness float64) (pool []Organism) {
pool = make([]Organism, 0)
// create a pool for next generation
for i := 0; i < len(population); i++ {
population[i].calcFitness(target)
num := int((population[i].Fitness / maxFitness) * 100)
for n := 0; n < num; n++ {
pool = append(pool, population[i])
}
}
return
}

What we do is to create a sort of breeding pool where I place a number of copies of the same organism according to its fitness into the pool. The higher the fitness of the organism, the more copies of the organism end up in the pool.

Create the next generation of the population from the selected best-fit organisms

After that we randomly pick 2 organisms from the breeding pool and use them as the parents to create the next generation of an organism for the population.

func naturalSelection(pool []Organism, population []Organism, target []byte) []Organism {
next := make([]Organism, len(population))
for i := 0; i < len(population); i++ {
r1, r2 := rand.Intn(len(pool)), rand.Intn(len(pool))
a := pool[r1]b := pool[r2]
child := crossover(a, b)
child.mutate()
child.calcFitness(target)
next[i] = child
}
return next
}

The next generation of the population must inherit the values of the genes

The child in the next generation is then bred from the crossover between 2 randomly picked organisms, and inherits the DNA from both organisms.

func crossover(d1 Organism, d2 Organism) Organism {
child := Organism{
DNA: make([]byte, len(d1.DNA)),
Fitness: 0,
}
mid := rand.Intn(len(d1.DNA))
for i := 0; i < len(d1.DNA); i++ {
if i > mid {
child.DNA[i] = d1.DNA[i]} else {
child.DNA[i] = d2.DNA[i]}
}
return child
}

For crossover, I simply picked a mid-point mid and use the first mid bytes from the first organism and the rest of the bytes from the second organism.

Randomly mutate each generation

After a new child organism has been reproduced from the 2 parent organisms, we see if the mutation happens to the child organism.

func (d *Organism) mutate() {
for i := 0; i < len(d.DNA); i++ {
if rand.Float64() < MutationRate {
d.DNA[i] = byte(rand.Intn(95) + 32)
}
}
}

Here mutation simply means determine if a randomly generated number is below MutationRate. Why do we need to mutate the child organism? If a mutation never occurs, the DNA within the population will always remain the same as the original population. This means if the original population doesn’t have a particular gene(value) that is needed, the optimal result will never be achieved. As in the example, if the letter t is not found in the initial population at all, we will never be able to come up with the quote no matter how many generations we go through. In other words, natural selection doesn’t work without mutations.

More technically speaking, mutations get us out of a local maximum in order to find the global maximum. If we look at genetic algorithms as a mechanism to find the optimal solution, if we don’t have a mutation, once a local maximum is found the mechanism will simply settle on that and never moves on to find the global maximum. Mutations can jolt the population out of a local maximum and therefore provide an opportunity for the algorithm to continue looking for the global maximum.

Once we check for mutation, we calculate the fitness of the child organism and insert it into the next generation of the population.

That’s all there is to the genetic algorithm! Now let’s put it all together in the main function.

func main() {
start := time.Now()
rand.Seed(time.Now().UTC().UnixNano())
target := []byte("To be or not to be")
population := createPopulation(target)
found := false
generation := 0
for !found {
generation++
bestOrganism := getBest(population)
fmt.Printf("\r generation: %d | %s | fitness: %2f", generation, string(bestOrganism.DNA), bestOrganism.Fitness)
if bytes.Compare(bestOrganism.DNA, target) == 0 {
found = true
} else {
maxFitness := bestOrganism.Fitness
pool := createPool(population, target, maxFitness)
population = naturalSelection(pool, population, target)
}
}
elapsed := time.Since(start)
fmt.Printf("\nTime taken: %s\n", elapsed)
}

In the main function we go through generations and for each generation we try to find the best fit organism. If the best fit organism’s gene is the same as the target we would have found our answer.

Now run the software program! How long did it take you?

Because the initial population is randomly generated, you will get different answers each time but most of the time we can evolve the quote in less than a second! That’s quite a vast difference from the 934 trillion years if we had to brute force it.

Evolving Shakespeare seems pretty simple. It’s just a string after all. How about something different, say an image? Or the most famous painting of all time, the Mona Lisa by Leonardo Da Vinci? Can we evolve that?

Mona Lisa (public domain)

Let’s give it the same treatment. We’ll start from defining the organism to represent the picture of Mona Lisa.

Define an organism consisting of one or more DNA

Instead of a byte array, our DNA is now a struct from the image standard library.

type Organism struct {
DNA *image.RGBA
Fitness int64
}

Start with an initial population of organisms

As before let’s look at creating an organism first.

func createOrganism(target *image.RGBA) (organism Organism) {
organism = Organism{
DNA: createRandomImageFrom(target),
Fitness: 0,
}
organism.calcFitness(target)
return
}

Instead of creating a random byte array, we call another function to create a random image.

func createRandomImageFrom(img *image.RGBA) (created *image.RGBA) {
pix := make([]uint8, len(img.Pix))
rand.Read(pix)
created = &image.RGBA{
Pix: pix,
Stride: img.Stride,
Rect: img.Rect,
}
return
}

An image.RGBA struct consists of a byte array Pix (byte and uint8 are the same thing), a Stride and a Rect. What’s important for us is the Pix, we use the same Stride and Rect as the target image (which is an image of Mona Lisa). Fortunately for us, the math/rand standard library has a method called Read that fills up a byte array nicely with random bytes.

You might be curious, so how big a byte array are we talking about here? Pix is nothing more than a byte array with 4 bytes representing a pixel (R, G, B and A each represented by a byte). With an image that is 800 x 600, we’re talking about 1.92 million bytes in each image! To keep the program relatively speedy, we’ll use a smaller image that is of size 67 x 100, which gives an array of 26,800 bytes. This, if you don’t realise it by now, is far from the 18 bytes we were playing around with in the last program.

Also, you might realise that because each pixel is now randomly colored, we’d end up with a colored static snow pattern.

Randomly generate image

Let’s move on.

Find the fitness of the organisms

The fitness of the organism is the difference between the two images.

// calculate the fitness of an organism
func (o *Organism) calcFitness(target *image.RGBA) {
difference := diff(o.DNA, target)
if difference == 0 {
o.Fitness = 1
}
o.Fitness = difference
}// find the difference between 2 images
func diff(a, b *image.RGBA) (d int64) {
d = 0
for i := 0; i < len(a.Pix); i++ {
d += int64(squareDifference(a.Pix[i], b.Pix[i]))
}
return int64(math.Sqrt(float64(d)))
}
// square the difference between 2 uint8s
func squareDifference(x, y uint8) uint64 {
d := uint64(x) - uint64(y)
return d * d
}

To find the difference, we can go back to the Pythagorean theorem. If you remember, we can find the distance between 2 points if we square the difference of the x and y values, add them up and then square root the results.

Pythagorean theorem

Give 2 points a(x1, y1) and b(x2, y2), the distance d between a and b is:

That’s in 2 dimensional space. In 3 dimensional space, we simply do the Pythagorean theorem twice, and in 4 dimensional space, we do it 3 times. The RGBA values of a pixel is essentially a point in a 4 dimensional space, so to find the difference between 2 pixels, we square the difference between r, g, b and a values of two pixels, add them all up and then square root the results.

That’s the difference between 2 pixels. To find the difference between all pixels, we just add up all the results together and we have the final difference. Because Pix is essentially one long byte array with consecutive RGBA values in it we can use a simple shortcut. We simply square the difference between each corresponding byte in the image and the target, then add them all up and square root the final number to find the difference between the 2 images.

As a reference, if 2 images are exactly the same, the difference will be 0 and if the 2 images are complete opposites of each other, the difference will be 26,800. In other words, the best fit organisms should have fitness of 0 and the higher the number is, the less fit the organism is.

Select the organisms with the best fitness and give them higher chances to reproduce

We’re still using the breeding pool mechanism here but with a difference. First, we sort the population from best fitness to worst fitness. Then we take the top best organisms and put them into the breeding pool. We use a parameter PoolSize to indicate how many of the best fit organisms we want in the pool.

To figure out what to put into the breeding pool, we subtract each of the top best organisms with the least fit organism in the top. This creates a differentiated ranking between the top best organisms and according to that differential ranking we place the corresponding number of copies of the organism in the breeding pool. For example, if the difference between the best fit organism and the least fit organism in the top best is 20, we place 20 organisms in the breeding pool.

If there is no difference between the top best fit organisms, this means the population is stable and we can’t really create a proper breeding pool. To overcome this, if the difference is 0, we set the pool to be the whole population.

func createPool(population []Organism, target *image.RGBA) (pool []Organism) {
pool = make([]Organism, 0)
// get top best fitting organisms
sort.SliceStable(population, func(i, j int) bool {
return population[i].Fitness < population[j].Fitness
})
top := population[0 : PoolSize+1]// if there is no difference between the top organisms, the population is stable
// and we can't get generate a proper breeding pool so we make the pool equal to the
// population and reproduce the next generation
if top[len(top)-1].Fitness-top[0].Fitness == 0 {
pool = population
return
}
// create a pool for next generation
for i := 0; i < len(top)-1; i++ {
num := (top[PoolSize].Fitness - top[i].Fitness)
for n := int64(0); n < num; n++ {
pool = append(pool, top[i])
}
}
return
}

Create the next generation of the population from the selected best-fit organisms

After we have the pool, we need to create the next generation. The code for natural selection here is no different from the previous program so we’ll skip showing it here.

The next generation of the population must inherit the values of the genes

The crossover function is slightly different as the child’s DNA is not a byte array but an image.RGBA. The actual crossover mechanism works on Pix, the byte array of pixels, instead.

func crossover(d1 Organism, d2 Organism) Organism {
pix := make([]uint8, len(d1.DNA.Pix))
child := Organism{
DNA: &image.RGBA{
Pix: pix,
Stride: d1.DNA.Stride,
Rect: d1.DNA.Rect,
},
Fitness: 0,
}
mid := rand.Intn(len(d1.DNA.Pix))
for i := 0; i < len(d1.DNA.Pix); i++ {
if i > mid {
child.DNA.Pix[i] = d1.DNA.Pix[i]} else {
child.DNA.Pix[i] = d2.DNA.Pix[i]}
}
return child
}

Randomly mutate each generation

The mutate function is correspondingly different as well.

func (o *Organism) mutate() {
for i := 0; i < len(o.DNA.Pix); i++ {
if rand.Float64() < MutationRate {
o.DNA.Pix[i] = uint8(rand.Intn(255))
}
}
}

Now that we have everything, we put it all together in the main function.

func main() {
start := time.Now()
rand.Seed(time.Now().UTC().UnixNano())
target := load("./ml.png")
printImage(target.SubImage(target.Rect))
population := createPopulation(target)
found := false
generation := 0
for !found {
generation++
bestOrganism := getBest(population)
if bestOrganism.Fitness < FitnessLimit {
found = true
} else {
pool := createPool(population, target)
population = naturalSelection(pool, population, target)
if generation%100 == 0 {
sofar := time.Since(start)
fmt.Printf("\nTime taken so far: %s | generation: %d | fitness: %d | pool size: %d",
sofar, generation, bestOrganism.Fitness, len(pool))
save("./evolved.png", bestOrganism.DNA)
fmt.Println()
printImage(bestOrganism.DNA.SubImage(bestOrganism.DNA.Rect))
}
}
}
elapsed := time.Since(start)
fmt.Printf("\nTotal time taken: %s\n", elapsed)
}

Now run it and see. What do you get?

Start evolving Mona Lisa

With the parameters I’ve set, when I run it, I usually start with a fitness of 19,000 or so. On an average it takes me more than 20 minutes before I reach a fitness of less than 7500.

After about 20 minutes

Here’s a sequence of images that’s been produced over time:

Evolving Mona Lisa

I had a bit of fun with evolving Mona Lisa by drawing circles and also drawing triangles on an image. The results weren’t as quick and the images were not as obvious but it shows a glimpse of what actually happens. You can check out the rest of the code from the repository and tweak the parameters yourselves to see if you can get better pictures but here are some images I got.

Mona Lisa triangles

Mona Lisa circles

Have fun!

You might have noticed in my screenshots that I actually displayed images on the terminal. I could have created a web application to show this but I wanted to keep things much simpler so I thought to display the images directly on the terminal. While the terminal console is not where you’d normally expect images to be displayed, there are actually several ways of doing it.

I chose one of the simplest. I happened to use the excellent iTerm2, which is a replacement for the default Terminal application in MacOS, and there is an interesting hack in iTerm2 that allows images to be displayed.

The trick is this — if you can encode your image in Base64, you can use a special command to print out images to the terminal. Here’s the Go code to do this, but you can also do this in any other language. There are several scripts in the documentation above that shows how this can be done using simple shell scripting.

func printImage(img image.Image) {
var buf bytes.Buffer
png.Encode(&buf, img)
imgBase64Str := base64.StdEncoding.EncodeToString(buf.Bytes())
fmt.Printf("\x1b]1337;File=inline=1:%s\a\n", imgBase64Str)
}

What this means, unfortunately, is that if you run this code in anything else other iTerm2, you won’t be able to see the evolution of the images. However, you can always tweak the output such that every few generations you capture the output.

All code and images in this post can be found here: https://github.com/sausheong/ga

The example code has been inspired by the following work:

  • Daniel Schiffman’s excellent book The Nature of Code http://natureofcode.com — it’s a great and easy to understand read! I also took some of Daniel’s code in Java and converted it to Go for the Shakespeare quote algorithm
  • Roger Johansson’s excellent work in the post Genetic Programming: Evolutiono of Mona Lisa https://rogerjohansson.blog/2008/12/07/genetic-programming-evolution-of-mona-lisa/– although I ended up using a completely different way of doing genetic algorithms, his original work gave me inspiration to use Mona Lisa and also to try doing it with triangles and circles
